2. Use Scope of Sublimation Silk Screen Ink
It applies to all kinds of screen printing machine.
3. Use Method of Sublimation Silk Screen Ink
In normal condition, use the ink on screen printer directly. The chemical for normal screen printing can be available to adjust
the ink attribution. First print image on paper by screen printer, then transfer the image from paper to fabric or other materials
by heat transfer press.
4. Available paper
80-120g wood pulp paper or kraft paper.
5. Printed materials
Fabric, mug, plate, metal, wood, ceramic, and etc.
6. Model & Coolor
S804- CMYK
7. Product Feature
Water based; ink granule is 15 um;120-300 DPI, 1kg ink can print 80-100m2 image.
8. Attention
(1) The color on paper and the color on fabric are different.
(2) When print the paper, the design should be mirror image. It means the image on paper is reverse, but after transfer on fabric,
the image will be right.
9. Transfer parameters
|
Fabric Name |
Transfer Temperature |
Transfer Pressure |
Transfer Time |
|
Polyester Fabric |
205°C~220°C |
0.5kg/cm2 |
10~30s |
|
Polyester low flexibility Fabric |
195°C~205°C |
0.5kg/cm2 |
30s |
|
Three-acetate fiber fabric |
190°C~200°C |
0.5kg/cm2 |
30~40s |
|
Nylon Fabric |
195°C~205°C |
0.5kg/cm2 |
30~40s |
|
Acrylic Fabric |
200°C~210°C |
0.5kg/cm2 |
30s |
|
Two-acetate Fabric |
185°C |
0.5kg/cm2 |
15~20s |
|
Gather propionitrile Fabric |
190°C~220°C |
0.5kg/cm2 |
10~15s |
For other materials, please refer to the above table. Mug, metal, ceramic, cotton needs sublimation coating before transferring.
10. Dye degree
|
Light Fastness |
Magenta |
Yellow |
Cyan |
Black |
|
5-6 |
6 |
2 |
2 |
11. Store: Avoid sunshine and water, sealed.
12. Shelf life: 1 year (from production date).
